This standard provides the design criteria for both the frequency-domain response (amplitude and phase) and time-domain response of the A-, B-, and C-weighting networks used in acoustically related measurements. The poles and zeros for each weighting network are given, along with equations for computing the amplitude and phase responses as functions of frequency and the impulse and step responses as functions of time. In the Appendix, similar information is provided for the D- and E-weighting networks.

The aim is to examine the design goal specifications of weighting networks for acoustical measurements. The scope is restricted to the design, or target, responses of weighting networks. Tolerances that belong in the instrument performance specifications are not included.

Product Details

Published:
10/22/2001
ANSI:
ANSI Approved
Number of Pages:
29
File Size:
1 file , 180 KB

Click here to purchase
This standard provides design information for the A-, B-, C-, D-, E-, G-, and U-weighting networks used for acoustical measurements. The analog poles and zeros for each weighting network are given, along with the equations for computing the magnitude and phase responses as functions of frequency. Coefficients and equations for computing the impulse and step responses of the A-, B-, C-, D-, and E-weighting networks as functions of time are provided in an informative annex. Information regarding digital implementation is also provided in an informative annex. Matlab scripts for the design of analog and digital implementations of the weighting networks described in this standard are also supplied.

Product Details

Published:
2020
ANSI:
ANSI Approved
File Size:
1 file , 1 MB
