1.1 This specification covers 39 grades of annealed titanium and titanium alloy forgings as follows:

1.1.1 Grade F-1Unalloyed titanium,

1.1.2 Grade F-2Unalloyed titanium,

1.1.2.1 Grade F-2HUnalloyed titanium (Grade 2 with 58 ksi minimum UTS),

1.1.3 Grade F-3Unalloyed titanium,

1.1.4 Grade F-4Unalloyed titanium,

1.1.5 Grade F-5Titanium alloy (6 % aluminum, 4 % vanadium),

1.1.6 Grade F-6Titanium alloy (5 % aluminum, 2.5 % tin),

1.1.7 Grade F-7Unalloyed titanium plus 0.12 to 0.25 % palladium,

1.1.7.1 Grade F-7HUnalloyed titanium plus 0.12 to 0.25 % palladium (Grade 7 with 58 ksi minimum UTS),

1.1.8 Grade F-9Titanium alloy (3 % aluminum, 2.5 % vanadium),

1.1.9 Grade F-11Unalloyed titanium plus 0.12 to 0.25 % palladium,

1.1.10 Grade F-12Titanium alloy (0.3 % molybdenum, 0.8 % nickel),

1.1.11 Grade F-13Titanium alloy (0.5 % nickel, 0.05 % ruthenium),

1.1.12 Grade F-14Titanium alloy (0.5 % nickel, 0.05 % ruthenium),

1.1.13 Grade F-15Titanium alloy (0.5 % nickel, 0.05 % ruthenium),

1.1.14 Grade F-16Unalloyed titanium plus 0.04 to 0.08 % palladium,

1.1.14.1 Grade F-16HUnalloyed titanium plus 0.04 to 0.08 % palladium (Grade 16 with 58 ksi minimum UTS),

1.1.15 Grade F-17Unalloyed titanium plus 0.04 to 0.08 % palladium,

1.1.16 Grade F-18Titanium alloy (3 % aluminum, 2.5 % vanadium) plus 0.04 % to 0.08 % palladium,

1.1.17 Grade F-19Titanium alloy (3 % aluminum, 8 % vanadium, 6 % chromium, 4 % zirconium, 4 % molybdenum),

1.1.18 Grade F-20Titanium alloy (3 % aluminum, 8 % vanadium, 6 % chromium, 4 % zirconium, 4 % molybdenum) plus 0.04 to 0.08 % palladium,

1.1.19 Grade F-21Titanium alloy (3 % aluminum, 2.7 % niobium, 15 % molybdenum, 0.25 % silicon),

1.1.20 Grade F-23Titanium alloy (6 % aluminum, 4 % vanadium, extra low interstitials, ELI),

1.1.21 Grade F-24Titanium alloy (6 % aluminum, 4 % vanadium) plus 0.04 to 0.08 % palladium,

1.1.22 Grade F-25Titanium alloy (6 % aluminum, 4 % vanadium) plus 0.3 to 0.8 % nickel and 0.04 to 0.08 % palladium,

1.1.23 Grade F-26Unalloyed titanium plus 0.08 to 0.14 % ruthenium,

1.1.23.1 Grade F-26HUnalloyed titanium plus 0.08 to 0.14 % ruthenium (Grade 26 with 58 ksi minimum UTS),

1.1.24 Grade F-27Unalloyed titanium plus 0.08 to 0.14 % ruthenium,

1.1.25 Grade F-28Titanium alloy (3 % aluminum, 2.5 % vanadium plus 0.08 to 0.14 % ruthenium),

1.1.26 Grade F-29Titanium alloy (6 % aluminum, 4 % vanadium, extra low interstitial, ELI plus 0.08 to 0.14 % ruthenium),

1.1.27 Grade F-30Titanium alloy (0.3 % cobalt, 0.05 % palladium),

1.1.28 Grade F-31Titanium alloy (0.3 % cobalt, 0.05 % palladium),

1.1.29 Grade F-32Titanium alloy (5 % aluminum, 1 % vanadium, 1 % tin, 1 % zirconium, 0.8 % molybdenum),

1.1.30 Grade F-33Titanium alloy (0.4 % nickel, 0.015 % palladium, 0.025 % ruthenium, 0.15 % chromium),

1.1.31 Grade F-34Titanium alloy (0.4 % nickel, 0.015 % palladium, 0.025 % ruthenium, 0.15 % chromium),

1.1.32 Grade F-35Titanium alloy (4.5 % aluminum, 2 % molybdenum, 1.6 % vanadium, 0.5 % iron, 0.3 % silicon),

1.1.33 Grade F-36Titanium alloy (45 % niobium),

1.1.34 Grade F-37Titanium alloy (1.5 % aluminum), and

1.1.35 Grade F-38Titanium alloy (4 % aluminum, 2.5 % vanadium, 1.5 % iron).

Note 1 – H grade material is identical to the corresponding numeric grade (that is, Grade 2H = Grade 2) except for the higher guaranteed minimum UTS, and may always be certified as meeting the requirements of its corresponding numeric grade. Grades 2H, 7H, 16H, and 26H are intended primarily for pressure vessel use.

The H grades were added in response to a user association request based on its study of over 5200 commercial Grade 2, 7, 16, and 26 test reports, where over 99 % met the 58 ksi minimum UTS.

1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
