1.1 This specification covers a system of color coding for one-mark pipets for identification of nominal capacities, and for graduated pipets for identification of nominal capacities and units of sub-division.
1.2 This specification applies to one-mark and graduated pipets of the nominal capacities listed in Table 1 and Table 2, respectively.
Note 1 – Many pipets not covered by other ASTM standards are included in Table 1 and Table 2, in order, firstly, to ensure uniformity of color coding as far as possible for non-standard as well as standard pipets and, secondly, to reserve suitable codes for possible future standards for other types of pipet.
TABLE 1 Coding System for One-Mark Pipets
Nominal Capacity, mL | Color Code Bands |
---|---|
0.001 | 1 blue |
0.002 | 2 red |
0.003 | 1 yellow |
0.004 | 2 green |
0.005 | 1 white |
0.01 | 1 orange |
0.015 | 2 blue |
0.02 | 1 black |
0.025 | 2 white |
0.03 | 2 yellow |
0.035 | 2 black |
0.04 | 2 red |
0.05 | 1 green |
0.075 | 2 orange |
0.1 | 1 blue |
0.15 | 1 white |
0.2 | 1 red |
0.25 | 2 green |
0.3 | 1 yellow |
0.4 | 2 red |
0.5 | 2 black |
1 | 1 blue |
2 | 1 orange |
3 | 1 black |
4 | 2 red |
5 | 1 white |
6 | 2 orange |
7 | 2 green |
8 | 1 blue |
9 | 1 black |
10 | 1 red |
15 | 1 green |
20 | 1 yellow |
25 | 1 blue |
30 | 1 black |
40 | 1 white |
50 | 1 red |
75 | 1 green |
100 | 1 yellow |
150 | 2 black |
200 | 1 blue |
TABLE 2 Coding System for Graduated Pipets
Nominal Capacity, mL | Sub-division, mL | Color Code Bands |
---|---|---|
0.01 | 0.001 | 1 blue |
0.05 | 0.001 | 1 yellow |
0.1 | 0.001 | 2 green |
… | 0.005 | 1 red |
… | 0.01 | 1 white |
… | 0.05 | 2 orange |
0.125 | 0.0125 | 2 yellow |
0.2 | 0.001 | 2 blue |
… | 0.002 | 2 white |
… | 0.01 | 1 black |
… | 0.1 | 1 orange |
0.5 | 0.005 | 1 green |
… | 0.01 | 2 yellow |
… | 0.02 | 2 red |
… | 0.05 | 2 black |
… | 0.25 | 2 green |
1 | 0.01 | 1 yellow |
… | 0.05 | 2 green |
… | 0.1 | 1 red |
1.5 | 0.01 | 2 red |
2 | 0.01 | 2 white |
… | 0.02 | 1 black |
… | 0.05 | 2 orange |
… | 0.1 | 1 green |
3 | 0.01 | 2 blue |
5 | 0.05 | 1 red |
… | 0.1 | 1 blue |
10 | 0.1 | 1 orange |
15 | 0.1 | 2 green |
20 | 0.1 | 2 yellow |
25 | 0.1 | 1 white |
… | 0.2 | 1 green |
50 | 0.1 | 2 orange |
… | 0.2 | 1 black |
100 | 0.2 | 1 red |
