1.1 The sound isolation between two spaces in a building is determined by a combination of the direct transmission through the nominally separating building element (as normally measured in a laboratory) and any transmission along a number of indirect paths, usually referred to as flanking paths. Fig. 1 illustrates the direct paths and some possible structural flanking paths. Additional non-structural flanking paths may include transmission through common air ducts between rooms, or doors to the corridor from adjacent rooms.

FIG. 1 Direct (D) and Some Indirect or Flanking Paths (F and Dotted) in a Building

Product Details

Published:
04/15/2014
Number of Pages:
15
File Size:
1 file , 250 KB
Redline File Size:
2 files , 590 KB
