1.1 This specification provides standard dimensions for manual (lever and gear actuator) butterfly valves installed in shipboard piping systems in NPS 2 to NPS 24, inclusive.
1.2 This specification covers conventional and ANSI B16.34 class butterfly valves of both lug and wafer types.
1.3 The values stated in inch-pound units are to be regarded as the standard. The values given in parentheses are for information only.
Product Details
- Published:
- 04/10/1998
- Number of Pages:
- 2
- File Size:
- 1 file , 28 KB
