CSA Preface

This is the first edition of CSA C22.2 No. 60730-2-22, Automatic electrical controls — Part 2-22: Particular requirements for thermal motor protectors, which is an adoption, with Canadian deviations, of the identically titled IEC (International Electrotechnical Commission) Standard 60730-2-22 (first edition, 2014-05). It replaces CAN/CSA-E730-2-2-94 (adopted IEC 730-2-2:1990), Automatic electrical controls for households and similar use — Part 2: Particular requirements for thermal motor protectors and it replaces CAN/CSA-E60730-2-4:13 (adopted IEC 60730-2-4:2006), Automatic electrical controls for household and similar use — Part 2-4: Particular requirements for thermal motor protectors for motorcompressors of hermetic and semi-hermetic type. It is one in a series of Standards issued by CSA Group under Part II of the Canadian Electrical Code. For brevity, this Standard will be referred to as “CSA C22.2 No. 60730-2-22” throughout. This Standard is intended to be used in conjunction with CSA E60730-1:15, Automatic electrical controls — Part 1: General requirements (adopted IEC 60730-1:2013), Amendment 1:2017 (adopted IEC Amendment 1:2015), and Amendment 2:2021 (adopted IEC Amendment 2:2020), with Canadian deviations. This Standard is considered suitable for use for conformity assessment within the stated scope of the Standard. This Standard was reviewed for Canadian adoption by the CSA Subcommittee on Automatic Controls for Household Use, under the jurisdiction of the CSA Technical Committee on Consumer and Commercial Products and the CSA Strategic Steering Committee on Requirements for Electrical Safety, and has been formally approved by the Technical Committee. This Standard has been developed in compliance with Standards Council of Canada requirements for National Standards of Canada. It has been published as a National Standard of Canada by CSA Group.

Scope and normative references

This clause of Part 12 is applicable except as follows:

1.1 Replacement: This part of IEC 60730 applies to the partial evaluation of thermal motor protectors as defined in IEC 60730-1 for household and similar use, including heating, air conditioning and similar applications as well as for sealed (hermetic and semi-hermetic type) motor-compressors.

NOTE A thermal motor protector is considered an integrated control since its protective functionality is dependent on the correct mounting and fixing in or on a motor and which can only be fully tested in combination with the relevant motor.

This dependency is illustrated by:

• the ability of the thermal motor protector to accurately and reliably sense the heat of the motor windings; thus, addressing the over-temperature protection due to motor overload conditions;

• the ability of the thermal motor protector to accurately and reliably sense the current due to motor locked-rotor conditions; thus, reducing the response time and not being adversely affected by heat-sink at the assembly spot in the application;

• the influence of the motor’s electromagnetic field on the switch behaviour of the thermal motor protector; particularly, affecting the arc direction between the contacts resulting in uneven wear of the contact material and eventually leading to failure of operation.

Requirements concerning the testing of the combination of sealed (hermetic and semi-hermetic type) motor-compressors and thermal motor protectors are given in IEC 60335-2-34. This standard applies to thermal motor protectors using NTC or PTC thermistors, additional requirements for which are contained in Annex J. 1.1.1 This standard applies to the inherent safety, to the operating values, operating times, and operating sequences, where such are associated with equipment safety, and to the testing of thermal motor protectors used in or on household or similar equipment as well as sealed (hermetic and semi-hermetic type) motor-compressors. This standard applies to thermal motor protectors for appliances within, but not limited to, the scope of IEC 60335-1 and its Part 2’s.

NOTE Throughout this standard, the word “equipment” means “appliance and equipment”. Thermal motor protectors not intended for normal household use, but which nevertheless may be used by the public, such as equipment intended to be used by laymen in shops, in light industry and on farms, are within the scope of this standard. This standard does not apply to thermal motor protectors designed exclusively for industrial applications.

1.1.2 This standard does not apply to other means of motor protection.

1.1.3 This standard does not apply to a manual device for opening the circuit.

1.5 Normative references Addition: IEC 60269-3, Low-voltage fuses – Part 3: Supplementary requirements for fuses for use by unskilled persons (fuses mainly for household and similar applications) – Examples of standardized systems of fuses A to F IEC 60335-2-34:2012, Household and similar electrical appliances – Safety – Part 2-34: Particular requirements for motor-compressors

Product Details

Edition:
1st
Published:
06/22/2023
ISBN(s):
9781488347276
Number of Pages:
96
File Size:
1 file , 2.5 MB
Product Code(s):
2430766, 2430766
Note:
This product is unavailable in Russia, Ukraine, Belarus
