This Practice provides the minimum requirements for ASME B73.1 pump baseplates and baseplates for general purpose pumps.

Comment: The function of a baseplate is to provide a structure under a pump and its driver that maintains alignment between the two components while accepting published piping loads. A pump properly supported and installed improves pump reliability and extends the operating life of such components as bearings, couplings, and seals.

This Practice describes minimum requirements for horizontal pump baseplates that are not covered in the API standards.

Product Details

Published:
05/01/2017
Number of Pages:
16
File Size:
1 file , 680 KB

Click here to purchase
This Practice provides designers and users with the minimum requirements for ASME B73.1M pump baseplates and baseplates for general purpose pumps that do not fall within ASME B73.1M dimensional and performance envelopes.

Baseplate requirements covered in this Practice are for horizontal pump designs described in ASME B73.1M and PIP RESP73H, and for general purpose pumps. Baseplate dimensional requirements shall be in accordance with ASME B73.1M except for free-standing baseplate designs and general purpose pumps that are not of the ASME B73.1M design. If a dimensional conflict arises between this practice and the AMSE B73.1M, this practice shall take precedence.

Product Details

Published:
05/01/2004
File Size:
1 file , 250 KB

Click here to purchase
This Practice describes minimum requirements for horizontal pump baseplates designed in accordance with ASME B73.1 and PIP RESP73H and for general purpose pump baseplates that are not within the dimensional and performance envelopes of ASME B73.1. This Practice includes two data forms.

Product Details

Published:
10/01/2010
Number of Pages:
16
File Size:
1 file , 610 KB
