This handbook is intended to accompany or incorporate AS5643 IEEE-1394b Interface Requirements for Military and Aerospace Vehicle Applications, AS5643/1 S400 Copper Media Interface Characteristics over Extended Distances, AS5657 Test Plan/Procedure for AS5643 IEEE-1394b Interface Requirements for Military and Aerospace Vehicle Applications, AS5706 Test Plan/procedure for AS5643/1 S400 Copper Media Interface Characteristics Over Extended Distances, and ARD5708 Frequently Asked Questions about IEEE-1394b and SAE AS5643. In addition, full understanding of this handbook also requires knowledge of IEEE-1394-1995, IEEE-1394a and IEEE-1394b standards.This handbook contains detailed explanations and architecture analysis on AS5643, bus timing and scheduling considerations, system redundancy design considerations, suggestions on AS5643-based system configurations, cable selection guidance, and lessons learned on failure modes.The purpose of this document is to provide application details, including explanations of AS5643, AS5643-based system design considerations, bus timing and scheduling, experiences on design tools, and lessons learned, that are not typically included in a SAE standard such as AS5643. It is intended to promote and support the use of SAE AS5643, and to serve as a platform for information exchange.
Product Details
- Published:
- 04/01/2009
- File Size:
- 1 file , 3.3 MB
