SAE J1113/27_201710: Vehicle electrical/electronic systems may be affected when immersed in an electromagnetic field generated bysources such as radio and TV broadcast stations, radar and communication sites, mobile transmitters, cellularphones, etc. The reverberation method is used to evaluate the immunity of electronic devices in the frequencyrange of 500 MHz to 2.0 GHz, with possible extensions to 200 MHz and 10 GHz, depending upon chamber sizeand construction. Optional pulse modulation testing at HIRF (High Intensity Radiated Fields) test levels, basedupon currently known environmental threats, has been added to this revision of the standard. This documentaddresses the Mode Stir (Continuous Stirring) Reverberation testing method which has been successfully utilizedas a design and production stage development tool for many years. The Mode Tuned (Stepped Tuner)Reverberation testing method is covered in the SAE J1113-28 document.
Product Details
- Published:
- 10/10/2017
- Number of Pages:
- 26
- File Size:
- 1 file , 1.1 MB
- Redline File Size:
- 2 files , 3.8 MB
