This SAE Recommended Practice defines the minimum functional requirements for quick connect couplings used for supply, return, and vapor/emission fuel system connections. This document also defines standard male tube end form dimensions, so as to guarantee interchangeability between all connector designs of the same male tube end form size. This document applies to automotive and light truck applications under the following conditions: a. Gasoline and diesel fuel delivery systems or their vapor venting or evaporative emission control systems; b. Operating pressure up to 500 kPa, 5 bar, (72 psig); c. Operating vacuum down to -50 kPa, -0.5 bar (-7.2 psi); d. Operating temperatures from -40 \mDC (-40 \mDF) to 115 \mDC (239 \mDF).

Quick connect couplings function by joining the connector to a mating tube end form, then pulling back to assure a complete connection. The requirements stated in this document apply to new connectors in assembly operations unless otherwise indicated. For service operations, the mating tube should be lubricated with SAE 30-weight oil before re-connecting.

Vehicle OEM fuel system specifications may impose additional requirements beyond the scope of this general SAE document. In those cases, the OEM specification takes precedence over this document.

Product Details

Published:
08/13/2009
File Size:
1 file , 380 KB

Click here to purchase

This SAE Recommended Practice defines the minimum functional requirements for quick connect couplings used for supply, return, and vapor/emission fuel system connections. This document also defines standard male tube end form dimensions, so as to guarantee interchangeability between all connector designs of the same male tube end form size. This document applies to automotive and light truck applications under the following conditions:

  1. Gasoline and diesel fuel delivery systems or their vapor venting or evaporative emission control systems.

  2. Operating pressure up to 500 kPa, 5 bar, (72 psig).

  3. Operating vacuum down to −50 kPa, −0.5 bar (−7.2 psi).

  4. Operating temperatures from −40 °C (−40 °F) to 115 °C (239 °F).

Quick connect couplings function by joining the connector to a mating tube end form, then pulling back to assure a complete connection. The requirements stated in this document apply to new connectors in assembly operations unless otherwise indicated. For service operations, the mating tube should be lubricated with SAE 30-weight oil before re-connecting.

Vehicle OEM fuel system specifications may impose additional requirements beyond the scope of this general SAE document. In those cases, the OEM specification takes precedence over this document.

Product Details

Published:
08/01/2009
File Size:
1 file , 380 KB
